Fill-Rite® DC 15 GPM Heavy Duty Fuel Transfer Pump with Battery Cable and Telescoping Pipe

SKU

FIL FR1210HN

Back Order Add to Compare

CA$571.99

Mobile Fuel Transfer Pump 12 Volt DC Heavy Duty 15 GPM - with Battery Cable, Telescoping Inlet Pipe only

Adjustable electric junction box that rotates 180 degree
Reliable heavy duty power switch lever to withstand heavy abuse in rugged environments
Focused weight reduction while perserving expected heavy duty performance
Thermally protected motor to prevent overheating to maximize motor life
Premium Paint Shield for explemplary corrosion resistance

Fuel Type	Gasoline, Diesel, Mineral Spirits
Included Components	Battery Cable, Telescoping Inlet Pipe only
Material of Construction	Cast Iron
Power Type	DC
Voltage [Volts]	12 VDC
Amperage [Amps]	20
Type of Pump	Rotary Vane
Inlet Size [Inch]	1
Inlet Thread Type	NPT
Outlet Size [Inch]	0.750000
Outlet Thread Type	NPT
Mounting	Bung Adapter 2in NPT
Maximum Flow Rate [GPM]	15
Bypass Pressure [PSI]	16
Maximum Suction Lift [ft]	8
Maximum Outlet Head [ft]	37
Minimum Dry Vacuum [in~HG]	5
Motor Type	Thermally Protected
Horse Power	0.250000
Motor Duty Cycle	30
RPM	2600
Recommended Circuit Protection [Amps]	30
Housing Material	Cast Iron
Rotor Material	Iron
Vane Material	Bronze
Colour	Red
Type of Power Supply	12 Volt
Inlet Connection	Female
Fluid Handling	Diesel Fuel, E15, Gasoline, Bio Diesel, Mineral Spirits
Motor Speed [RPM]	2600
Max Discharge Pressure [PSI]	16
Max Operating Pressure [PSI]	16
Current Range [A]	20-20
Cable Connection	Bare Leads
Flow Rate Range [GPM]	0 - 15
Mounting Thread	NPT
Maximum Operating Temperature [deg C]	60
Hold Open Clip?	No
Pump Housing Material	Cast Iron
Strainer Mesh Material	Stainless
Outlet Type	Female
Compatible Fuels	Bio Diesel up to B20, Gasoline, Diesel, Mineral Spirits
Connection Type	NPT
Strainer Mesh Size [Micron]	20 x 20
